8'' 800x480 RGB TFT LCD display panel AT080TN64

A grade new original,12months warranty

Brand Name: InnoLux

Luminance(nits): 450

Contrast(%): 500

Display Mode: TN,normally white,transmissive

Viewing Angle: 50/70/70/70

Interface: 50pin FPC,parallel 24bit RGB(TTL)

Operation Temperature: -30~85℃

Outline Dimension: 192.8*116.9*6.4(mm)

Touch Screen: 4-wire resistive touch screen

MOQ:1PC

Contact now

Introduction

General Description:
AT080TN64 is a transmissive type color active matrix liquid crystal display (LCD), which uses amorphous thin film transistor(TFT) as switching devices. This panel has a 8.0 inches diagonally measured active display area with WVGA (800 RGB x 480) resolution.
AT080TN64 is designed with high luminance 500nits so that it has good display effect.

Matching resistive touch screen and HDMI control board is available.


Packaging Form:

Amount per Box:30pcs

Box Size: 530*355*255 mm(L*W*H)
Box Gross Weight: 9.8Kgs


Payment Terms: 100% in Advance
