15'' touch screen, 5 wire resistive type, USB/RS232 controller optional
Quick Details
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Control
- Model Number: TP15W5BZ
- Type: Touch screen for TFT LCD panel
- Outline Dimension: 322.00 x 247.00 (mm)
- View Area: 310.50 x 236.00 (mm)
- Active Area: 304.00 x 228.00 (mm)
- Operating Voltage: ≤10V
- Operation Temperature:-10℃~60℃
- Storage Temperature: -20℃~70℃
- Life Time: >1,000,000 times
- Surface Hardness: ≥3H(pencil)
- Response time: ≤10ms
- Transmittance: ≥85%
Introduction
15'' touch screen, 5 wire resistive type, USB/RS232 controller optional
1.Touch panel drawing
2. Picture
1.Packaging:
2. Shipping ways:
1)Packing---Forwarder---HK Port---DHL---Tracking number
Or HK warehouse----Forwarder----DHL tracking number
Or Taiwan warehouse----Forwarder---DHL tracking number
2)Contact DHL/UPS/FedEx directly with customer's account
3)To be picked up
We supply A grade new original InnoLux and AUO LCD panels.
Matching touch screens and driver boards are also available.
We advise our customers:
1)Please contact us for detailed specifications and check them carefully before choosing a LCD module, touch screen or driver board.
2)Please do let us know if quantity and presentation quality are OK within 1 week after signing the goods.
3)Please share information as much as possible when you meet a problem in using our products. That will do us a great favor to find a solution.
4)We are responsible for our LCD parts but joint responsibility is not included.
